The NH-KVVV Fire Resistant LSZH Cable is a high-quality control cable featuring a fire-resistant PVC insulation and sheath. Rated at 450/750V, it utilizes high-purity oxygen-free copper conductors wrapped in mica tape for enhanced safety. The cable provides reliable performance in critical applications requiring fire resistance and low smoke zero halogen (LSZH) properties, ensuring minimal toxic emissions during combustion. Suitable for use in various industrial and commercial environments, it meets stringent safety and durability standards.
- Control circuits for AC rated voltage up to 450/750V
- Monitoring circuits with specific safety requirements
- Protective circuits in environments with high fire safety demands
- Ideal for fire-resistant applications with stringent standards
| Electrical Performance | Voltage | AC 450/750V |
| Rated Temperature | 70°C | |
| Construction | Conductor | Bare Copper |
| Fire-Resistant Layer | Mica Tape | |
| Insulation | PVC | |
| Sheath | PVC | |
| Flame Retardance | Compliant with IEC 60332-1-2 | |
| Default Sheath Color | Black (other colors available upon customer request) | |
